Description
Features
- Portable, compact, and lightweight
- Rugged 24v solid-state thermoelectric heat pumps
- OLED display with power monitor
- IP-rated switching power supply
- Variable DC voltage PID controller for thermoelectric module
- Integrated peristaltic pump for condensate removal
- Easily removable condenser
- Insulated aluminum cold block
- Dual high-output axial fans are coupled with thermosiphon heat exchangers to support the thermoelectric units and allow the gas conditioner to operate in a wider range of ambient conditions
Specifications
- Pinnacle Heat Pump System: Two 80-watt solid-state modules
- Temperature Display: OLED display +/- 0.1 °C/°F
- Temperature Control: Variable DC voltage controller, 3-button keypad
- Cold Block: Insulated aluminum
- Condenser: Alloy 316 stainless steel, reverse flow condensate separator, various coatings available, 1” OD x 12”
- Condensate Removal: Integrated peristaltic pump, 10 ml/min
- Radiator: Two high flow, low-profile heat sinks 120-mm axial fans, with encapsulated motor and electronics
- Rated Moisture Extraction Capacity: 14% moisture at 10 lpm (75° ambient) with a less than 1% target moisture rate.
- Auxiliary Temperature Controllers: Digital temperature controllers for probe, oven, and heated jumper; type-K thermocouple input
- Ambient Operating Temperature: 32 to 104 °F (0 to 40 °C) Standard Flow Rate: 1 to 15 lpm, single channel Tubing Size: 1/4“ diameter standard or 3/8” fittings provided
- Accessories: Companion condenser, peristaltic pump (optional), separate strain reliefs
- Dimensions: 10.25” W x 16.5” H x 9.25” D (260 mm W x 419 mm H x 235 mm D) Weight: 30.7 lbs (13.9 kg)
